Nominal Impedance    4 Ohm
Power Handling    160W
Max. Transient Power Handling    1000W
Sensitivity (2.83V/1M)    89dB
Frequency Response    35-5000Hz
FS    55Hz
Voice Coil Diameter    75mm (3")
Voice Coil Height    14.5mm (0.57")
Voice Coil Type/Former    Aluminum
Voice Coil Wire    Hexatech Aluminum
DC Resistance    3.7 Ohm
Voice Coil Inductance @1kHz    0.39MH
Magnet System    Hybrid rear vented
HE-Magnetic Gap Height    6mm (0.25")
B-Flux Density    0.8T
BL Product/BXL    41075
Max. Linear Excursion/Xmax    8.5mm (±4.25mm)
Suspension Compliance CMS    676
Mechanical Q Factor QES    0.42
Total Q Factor Q/T    0.35
QMS    1.99
Mechanical Resistance RMS    1.03kgS1
Moving Mass MMS    11.8gr (0.42oz)
Equivalent Car Air Load VAS    8.00L (0.28ft3)
Effective Pison Area SD    90cm2 (13.95in2)
Cone Type    One-piece formed
Cone Material    DPC
Unit Diameter    135mm (51")
Mounting Depth    60mm (2.36")
Mounting Cutout    120mm (4.72")
Net Weight    1.05kg (2.31lb)
