Voltage  11 ÷ 15 VDC
Idling current   0.4 A
Switched off without DRC  2.5 mA
Switched off with DRC  4 mA
Remote IN voltage  7 ÷ 15 VDC (1.3 mA)
Remote OUT voltage  12 VDC (130 mA)
High Level (Speaker)  FL - FR - RL - RR - PHONE IN
Low Level (Pre)  AUX IN
Low Level Pre (Default)  FRONT L/R, REAR L/R, SUB
From / to personal computer  1 x USB / B (1.1/2.0)
Distortion-THD @ 1 kHz, 1V RMS Output   0.005 %
Bandwidth @ -3 dB  10 ÷ 22k Hz
S/N Ratio @ weighted
Master Input  95 dBA
Aux Input  96 dBA
Channel Separation (@ 1 kHz)  85 dB
Input sensitivity (Speaker In)  2 ÷ 15 V RMS
Input sensitivity (AUX in)  0.6 ÷ 5 V RMS
Input sensitivity (PHONE)   2 ÷ 15 V RMS
Input impedance (Speaker In)  2,2 k?
Input impedance (AUX in)  15 k?
Input impedance (PHONE)   2,2 k?
Max Output Level (RMS) @ 0.1% THD  4 V RMS
Mode  Full / High Pass/ Low Pass/ Band Pass
Type and slope   Linkwitz @ 12/24 dB
Butterworth @ 6/12/18/24 dB
Crossover frequency   68 steps @ 20 ÷20k Hz
Phase control  0° ÷ 180°
Hi-Level Input (Speaker In)   Automatic De-Equalization
Outputs   N.5 Graphic: ± 12 dB @ 31 Band ISO 1/3 Oct. 20 ÷ 20k Hz
Distance   0 ÷ 510 cm / 0 ÷ 200.8 in.
Delay  0 ÷ 15 ms
Step  0,08 ms; 2,8 cm / 1.1 in.
Fine set  0,02 ms; 0,7 cm / 0.27 in.
W x H x D (mm / in.)  191 x 34 x 131 / 7.51 x 1.33x 4.76
Weight (kg / lb.)  0,6 /1.322
